Maintained, restored, and upgraded by the last three owners, Rosita is ready to take the lucky buyer cruising wherever they wish. Recent upgrades include a professionally rebuilt motor, high power alternator, dual anchor windlass, sturdy roller reefing, colorful drifter, barrier coated bottom, and propane system with oven. Some may fault the laminate finished bulkheads but the interior remains in great shape for a boat of this vintage. Her sturdy, full-length keel encourages the skipper to explore those shallow protected anchorages while providing the sea-keeping ability that enabled the current owner to weather the after-effects of Hurricane Ivan with confidence. If you want a quality, classic cruising vessel, consider Rosita's specifications below.

Builder: Allied Boat Co.
Designer: Arthur Edmonds
LOA: 36' LWL: 27'6" Beam: 11'
Displacement: 14400 Draft: 4'6" Bridge Clearance: 46' + 48" antenna
Ballast: 5000
Engine: Perkins 4-108 (50 hp) rebuilt 2007
Hours: approx. 10 hours on professional rebuild
Cruising Speed: 7 knots, max. 8 - 9 knots
Original integral fuel tank 40 gal (needs refurbished or replaced)
Auxiliary fuel tank: 18 gal, mounted under port cockpit seat
Water tank: 80 gal stainless steel, original
Holding tank: 15 gal plastic

Starting forward is a V-berth with storage beneath the berth, four storage drawers, storage along the hullsides, anchor locker access forward, an overhead opening hatch, and two opening ports. An extra large combination hanging-storage locker, plus a privacy door leading aft. Aft to port is the head with manual marine toilet, hand-held shower, storage for toiletries, plus a separated vanity with sink.

Just aft is the salon. To port there is a L-shaped settee (sleeps one), storage beneath the berth, storage along the hullside, 2 opening ports, a fixed dinette, plus an opening overhead hatch. To starboard is a six-drawer storage cabinet followed by a large settee (sleeps one), storage beneath the settee, storage along the hullside, two opening ports.

Just aft is the galley with a new 3-burner Force 10 propane stove with oven, stainless steel sink, pressure fresh water system, an ice box/refrigerator, plus ample storage for food and dishware. Across to port is a large navigation station with four drawer storage beneath and access to the aft quarter berth.

* All interior cushions were replaced in 2001.

Galley
3 burner stainless steel Force 10 stove with oven (2003)
20# propane aluminum tank w/remote shut-off (2003)
Stainless steel sink
Pressure fresh water system
Icebox with NovaKool cold plate refrigeration added (needs repair)
Propane BBQ grill (rail mount)

Electronics & Navigation
New stereo CD player with four interior speakers and two cockpit speakers
Autohelm 4000 autopilot
Two VHF radios
One handheld VHF radio
Horizon Knotmeter, Depthsounder and Wind Indicator
Ritchie 8" Compass with brass binnacle
Windex
Radar reflectors

Electrical System
30 amp 110 volt AC electrical system with 50' shore power cord
Built-in CruisAir heat pump air conditioning system
(heat & cool, 110 AC, runs great manually but controller needs work)
12 volt DC electrical system
New LED running lights and tricolor masthead light (masthead light not installed)
4 AGM sealed no-maintenance house batteries
Group 27 starter battery (New 2004)
Link 1000 battery monitor
100 amp alternator (original alternator in storage)
20 amp battery charger
Zinc saver current isolator
250 watt inverter
Battery parallel switches

Engine Room & Mechanical
Racor 500 primary fuel filter
Westerbeke secondary fuel filter
Fuel shut-off valve
wheel steering, Edson worm gear, SS wheel
Morse lever/cable engine controls
Hurth HBW100 2:1 transmission
1 Auto, 1 manual, & 1 electric bilge pumps
Remote oil change pump (2003)
Remote bypass oil filtration system (10 micron primary and 2 micron secondary, 2003)
3-blade bronze propeller (trued in 2004)
Three fire extinguishers
Seaward hot water tank (not connected to engine cooling system)

Hull and Deck
Bottom has barrier coat by previous owner (evidence of previous minor blister repair)
No blisters found in last two haulouts
Topsides and deck finished with Awlgrip "Moondust" paint
New cutlass bearing installed 2004
Canvas, tan Sunbrella: Large bimini top, large dodger, main and mizzen sail covers, roller furler sun stripe
Mahogany cockpit coamings
Teak handrails on cabin top
Mahogany winch islands and caprails
2 aluminum frame opening hatches
6 Lewmar opening port lights
Full length aluminum rub rails
Cockpit "Bottomsider" cushions
Lifesling mounted on stern rail
Two opening seats and two hatches in cockpit for storage access
Stainless steel boarding ladder (transom mount)
Repaired rot in stbd fwd bulkhead cause by leak in chainplate (all chainplates rebedded 2004)

Anchor System
Two electric anchor windlasses (New 2003)
45# Delta galvanized anchor, primary (new 2004)
35# CQR galvanized anchor, secondary (painted)
20# HT Danforth galvanized anchor (new 2003)
75' 5/16" HT galvanized chain w/ 200' 9/16" rode (two)
200' 5/8" spare anchor line
10# anchor kellet
Stainless steel anchor platform, original (roller replaced 2003)
Secondary anchor roller installed 2004
Two 12" deck cleats

Sails and Rigging
Stainless steel wire rigging (professionally inspected in 2002 at survey)
Mian chainplates upgraded in 2005 (new 1/4" x 1-1/2" replaced 3/16" x 1-1/4" original)
Aluminum extrusion Main and mizzen masts & booms
Furlex (by Selden) roller reefing on forestay
Sails: main, mizzen, 135% genoa on roller furler, drifter, storm jib
Reef points: Main sail with 2 reef points, Mizzen with single reef point, roller reefing jib
End-boom sheeting -Main & Mizzen
2 Lewmar #40 primary winches
2 Lewmar #8 Halyard winches
2 winch handles
Low-stretch rope life lines (new 2003, removed in berth or storage)

Remarks
This vessel was hauled November 2004 to have bottom sanded, new bottom paint, and new zincs. No indication of blisters. Launched in March, 2005, Rosita was in the water only four months before hauling in June 2005 for storage in Palmetto, FL. In March 2007, she was launched and taken to Tarpon Springs, FL.
