4mm Zimmerstutzen

Front loader. Uses 4.35mm graphited balls and a 4mm case. The indoor rifles were shot at 15m.
Zimmerstutzen looks like its 8.15 X 46mm Schuetzen mate.
Zimmerstutzen looks like its 8.15 X 46mm Schuetzen mate.
Zimmerstutzen Butt Stock
Zimmerstutzen Butt Stock
Nicely carved and finished curly grained wood adds beauty
Nicely carved and finished curly grained wood adds beauty
The Trigger Guard is the cocking piece.
The Trigger Guard is the cocking piece.
Showing Set Triggers
Showing Set Triggers
Typical Fore End
Typical Fore End
Action ready to shoot
Action ready to shoot
Front Loaded Zimmerstutzen Action
Front Loaded Zimmerstutzen Action
Removable sight insert allows different sized front sight beads to be used.
Removable sight insert allows different sized front sight beads to be used.
Spring assists in opening the action.
Spring assists in opening the action.
Locking latch open
Locking latch open
Chamber swung out for extraction of fired case
Chamber swung out for extraction of fired case
Partially extracted fired case
Partially extracted fired case
Pressing down on checkered thumb piece pushes case out
Pressing down on checkered thumb piece pushes case out
Front loader requires separate ball and case
Front loader requires separate ball and case
Breech locked and ready to fire
Breech locked and ready to fire
Spanner wrench holes , bore in the center.
Spanner wrench holes , bore in the center.
6 A is the German marking of ball size of the bore
"6 A" is the German marking of ball size of the bore
